5400-S5-8 DANFOSS 5400 Series Low Air Inclusion Refrigerant Female No Adapter Quick Disconnect Coupling with Guardian Seal Plating
5400-S5-8 DANFOSS | COUPLING, REFRIG

Manufacturer: DANFOSS
Manufacturer Model #: 5400-S5-8
DANFOSS HANSEN AND GROMELLE 5400 SERIES QUICK DISCONNECT COUPLINGS SOCKET
Quick connect and disconnect|No need for special tools|Exceeds ISO 16028 operating pressures

Angle shape: Straight
Body size: 1/2
Burst Pressure: 5200 psi
Currency: USD
Eccn: EAR99
End gender 1: Female
End gender 2: Female
End size 1: 1/2 IN
End Size 2: 1 IN
End type 1: NPT
End Type 2: NPT
Finish plating: Guardian Seal
Flow Rate: 14 gallons per minute
Hex size 1: 1.18 inch
Hex size 2: 1.02 inch
Hose id: 0.5
Item type: Female Half
Net pack quantity: 0
Net pack quantity units: EA
Nmfc: 50
Part status: AC
Product height: 1.30
Product height uom: inch
Product length: 1.60
Product length uom: inch
Product material: Carbon steel
Product trade name: 5400 Series
Product weight: 0.26
Product weight uom: pound
Product width: 1.18
Product width uom: inch
Seal Material: Neoprene
Segment code: A
Sub brand: Hansen and Gromelle
Thread sealant: No
Thread size 1: 1-20
Thread size 2: 1-20
Working Pressure: 400 PSI
