Parker 针阀
Parker Needle Valves
Rising Plug Valve, 10,000 PSI - H Series

These unique, high quality, high performance, low torque rising plug soft-seated valves have been specifically designed to perform with fluids containing high levels of contamination frequently found in oil and gas processing facilities.





The Parker rising plug valve offers complete customer system compatibility that reduces installation time and potential leak paths. The rising plug valve operates a straight through flow path which is ideal for handling viscous fluids. The soft seat deign is tolerant of small particulates found in the media which ensures leak free operation once valve is closed - vital for system safety. Further safety features include the multi turn open and close function, with gradual opening ensuring safer operation that avoids sudden pressure surges, ultimately protecting the integrity of the system. The rising plug valve is rated to 10,000 PSI as standard, with range of end different connections, including Parker's two and single ferrule fittings. Retrofitting anti tamper devices, hand and locking wheels can all be achieved in the field.



Rising Plug Valve, 10,000 PSI - H Series



Markets:
- Oil and Gas Offshore
- Oil and Gas Onshore
- Refining
- Petrochemical
- Chemical

Features / Benefits:
- Straight through flow path
- Soft seat design ensures leak free operation
- Gradual opening avoids pressure surges
- Integral ended connections saves installation time

Applications
- Lubrication skids
- Gas cylinder filling stations
- Instrumentation isolation lines



Technical Specifications

Inlet Connection Size: 1/4 (NPT), 1/2 (NPT) inch, Female, Male
Outlet Connection Size: 1/4 (NPT), 1/2 (NPT), 3x 1/2 (NPT) inch, Female
Materials of Construction: Stainless Steel, Monel, Duplex, Super Duplex, Hasteloy, 6Mo, Titanium, Incoloy 825, Incoloy 625
Seat Material: PEEK soft seat
Maximum Operating Pressure: 10000 (9000 for Monel) psi, 689 (621 for Monel) bar
Packing Material: PTFE
Mounting Option: Base mount
Maximum Operating Temperature: 200 °C, 392 °F
Product Series: H



Rising Plug Valve, 10,000 PSI - H Series 型号

Part Inlet Size (inch) Inlet Connection Outlet Size (inch) Outlet Connection Material
HRPV46254FF 1/4 NPT Female 1/4 NPT Female Incoloy 625
HRPV46258FF 1/2 NPT Female 1/2 NPT Female Incoloy 625
HRPV46258M8F 1/2 NPT Male 1/2 NPT Female Incoloy 625
HRPV46MO4FF 1/4 NPT Female 1/4 NPT Female 6Mo
HRPV46MO8FF 1/2 NPT Female 1/2 NPT Female 6Mo
HRPV46MO8M8F 1/2 NPT Male 1/2 NPT Female 6Mo
HRPV48254FF 1/4 NPT Female 1/4 NPT Female Incoloy 825
HRPV48258FF 1/2 NPT Female 1/2 NPT Female Incoloy 825
HRPV48258M8F 1/2 NPT Male 1/2 NPT Female Incoloy 825
HRPV4D14FF 1/4 NPT Female 1/4 NPT Female Duplex
HRPV4D18FF 1/2 NPT Female 1/2 NPT Female Duplex
HRPV4D18M8F 1/2 NPT Male 1/2 NPT Female Duplex
HRPV4D24FF 1/4 NPT Female 1/4 NPT Female Super Duplex
HRPV4D28FF 1/2 NPT Female 1/2 NPT Female Super Duplex
HRPV4D28M8F 1/2 NPT Male 1/2 NPT Female Super Duplex
HRPV4HC4FF 1/4 NPT Female 1/4 NPT Female Hasteloy
HRPV4HC8FF 1/2 NPT Female 1/2 NPT Female Hasteloy
HRPV4HC8M8F 1/2 NPT Male 1/2 NPT Female Hasteloy
HRPV4M4FF 1/4 NPT Female 1/4 NPT Female Monel
HRPV4M8FF 1/2 NPT Female 1/2 NPT Female Monel
HRPV4M8M8F 1/2 NPT Male 1/2 NPT Female Monel
HRPV4S4FF 1/4 NPT Female 1/4 NPT Female Stainless Steel
HRPV4S8FF 1/2 NPT Female 1/2 NPT Female Stainless Steel
HRPV4S8M8F 1/2 NPT Male 1/2 NPT Female Stainless Steel
HRPV4T4FF 1/4 NPT Female 1/4 NPT Female Titanium
HRPV4T8FF 1/2 NPT Female 1/2 NPT Female Titanium
HRPV4T8M8F 1/2 NPT Male 1/2 NPT Female Titanium
HRPVG46258M8F 1/2 NPT Male 3 x 1/2 NPT Female Incoloy 625
HRPVG46MO8M8F 1/2 NPT Male 3 x 1/2 NPT Female 6Mo
HRPVG48258M8F 1/2 NPT Male 3 x 1/2 NPT Female Incoloy 825
HRPVG4D18M8F 1/2 NPT Male 3 x 1/2 NPT Female Duplex
HRPVG4D28M8F 1/2 NPT Male 3 x 1/2 NPT Female Super Duplex
HRPVG4HC8M8F 1/2 NPT Male 3 x 1/2 NPT Female Hasteloy
HRPVG4M8M8F 1/2 NPT Male 3 x 1/2 NPT Female Monel
HRPVG4S8M8F 1/2 NPT Male 3 x 1/2 NPT Female Stainless Steel
HRPVG4T8M8F 1/2 NPT Male 3 x 1/2 NPT Female Titanium
