Compression Fitting, 15,000 PSI - SW Series
Parker's SW Series is designed for low-pressure, 15,000 PSI and utilizes the Autoclave's Speed Bite connection for secure installation. This single-ferrule compression sleeve connection provides easy make-up and reliable bubble-tight performance.
Parker Autoclave's SW Series utilizes the proven Speed Bite connection. This fitting is designed with a single ferrule compression sleeve for systems up to 15,000 PSI (1034 BAR). This connection delivers fast, easy make-up and reliable bubble-tight performance, in a variety of liquid or gas service applications. Installers will appreciate the low make-up torque with the Molybdenum Disulfide coated nuts. This key feature also helps to prevent galling during installation.
Compression Fitting, 15,000 PSI - SW Series
Markets:
- Chemical
- Petro-Chemical
- Oil and Gas
Features/Benefits:
- Single-ferrule compression sleeve
- Fast easy make-up of connection
- Tubing sizes are 1/16”,1/8", 1/4", 3/8", and 1/2"
- Fittings manufactured from cold worked 316 stainless steel
- Molybdenum disulfide-coated gland nuts to prevent galling
- Operating temperatures from 0°F (-17.8°C ) to 650°F (343°C)
Applications:
- Fluid handling Systems
- Skid Panel Fabricators
- Testing Panels
Technical Specifications
| Fitting Type: |
Compression / Flareless |
| Maximum Operating Pressure: |
15,000, 10,000 psi, 1034, 689 bar |
| Assembly: |
Special Tool Required |
| Connection Type: |
W125 , SW250 , SW375 , SW500 |
| Shape: |
Elbow, Tee, Cross, Straight Coupling , Bulkhead Couplings |
| Materials of Construction: |
316 Stainless Steel |
| Maximum Tube Outside Diameter: |
1/8, 1/4, 3/8, 1/2 inch, 3.18 , 6 , 10 , 12.70 mm |
Compression Fitting, 15,000 PSI - SW Series 型号
| Part |
Connection Type |
Shape |
Material |
Maximum Tube O.D (inch) |
Maximum Tube O.D (mm) |
| 15BF2211 |
W125 |
Bulkhead Couplings |
316 Stainless Steel |
1/8" |
3.18 mm |
| 15F2211 |
W125 |
Straight Coupling |
316 Stainless Steel |
1/8" |
3.18 mm |
| 4BF8822 |
SW500 |
Bulkhead Couplings |
316 Stainless Steel |
1/2" |
12.70 mm |
| 4F8822 |
SW500 |
Straight Coupling |
316 Stainless Steel |
1/2" |
12.70 mm |
| 6BF4422 |
SW250 |
Bulkhead Couplings |
316 Stainless Steel |
1/4" |
6 mm |
| 6BF6622 |
SW375 |
Bulkhead Couplings |
316 Stainless Steel |
3/8" |
10 mm |
| 6F4422 |
SW250 |
Straight Coupling |
316 Stainless Steel |
1/4" |
6 mm |
| 6F6622 |
SW375 |
Straight Coupling |
316 Stainless Steel |
3/8" |
10 mm |
| SL2200 |
W125 |
Elbow |
316 Stainless Steel |
1/8" |
3.18 mm |
| SL4400 |
SW250 |
Elbow |
316 Stainless Steel |
1/4" |
6 mm |
| SL6600 |
SW375 |
Elbow |
316 Stainless Steel |
3/8" |
10 mm |
| SL8800 |
SW500 |
Elbow |
316 Stainless Steel |
1/2" |
12.70 mm |
| ST2220 |
W125 |
Tee |
316 Stainless Steel |
1/8" |
3.18 mm |
| ST4440 |
SW250 |
Tee |
316 Stainless Steel |
1/4" |
6 mm |
| ST6660 |
SW375 |
Tee |
316 Stainless Steel |
3/8" |
10 mm |
| ST8880 |
SW500 |
Tee |
316 Stainless Steel |
1/2" |
12.70 mm |
| SX2222 |
W125 |
Cross |
316 Stainless Steel |
1/8" |
3.18 mm |
| SX4444 |
SW250 |
Cross |
316 Stainless Steel |
1/4" |
6 mm |
| SX6666 |
SW375 |
Cross |
316 Stainless Steel |
3/8" |
10 mm |
| SX8888 |
SW500 |
Cross |
316 Stainless Steel |
1/2" |
12.70 mm |
|
