Parker Needle Valves
Needle Valve,Mini Block and Bleed MVBB Series - 20,000 PSI
Parker Autoclave's MVBB Series is a mini block and bleed valve that is designed for blocking, bleeding, and calibration of instrumentation systems. This valve is a rotating rising stem design, rated to 20,000 psi (1379 bar).
Parker Autoclave's MVBB Series mini block and bleed needle valves are a two stem manifold valve providing an economical and convenient method of blocking, bleeding and calibrating pressure transmitters and gauges. The valve utilizes the mini valve packing and stem design making it compact and easy to use. The valve can be surface or panel mounted for safe operation. In addition, manifold style valves reduce the number of fittings and space required for installation.
These valves have a rising stem bar stock body design with working pressures to 20,000 psi (1379 bar). The cone and thread connections utilize Parker Autoclave tubing with sizes from 1/4" to 3/8”". Operating temperatures can go from 0°F to 800°F (-17.8°C to 427°C) with special graphite braided yarn packing (GY). 316 stainless steel construction is the standard material with other options available. Along with their many features these valves provide dependable and trouble free service in wide variety of applications.
Needle Valve,Mini Block and Bleed MVBB Series - 20,000 PSI
Markets:
- Oil and Gas
- Petrochemical
- Chemical
Features/Benefits:
- MVBB Series valve design provides large valve performance in a small package
- Tubing sizes: 1/4" and 3/8"
- Rising stem/bar stock body design.
- Metal-to-metal seating achieves bubble-tight shut-off, longer stem/seat life in abrasive flow, greater durability for repeated on/off cycles and excellent corrosion resistance.
- PTFE encapsulated packing provides dependable stem and body sealing.
- Stem and packing gland design have been selected to achieve extended thread cycle life and reduced handle torque.
Applications:
- Calibrating Transmitters
- Gauge Testing
- High Pressure Fluid handling
Technical Specifications
| Maximum Operating Pressure: |
1379 bar |
| Tube Outside Diameter: |
1/4, 3/8 inch |
| Connection Type: |
SF250CX , SF375CX |
| Bore Diameter: |
0.094 inch, 2.39 mm |
Needle Valve,Mini Block and Bleed MVBB Series - 20,000 PSI 型号
| Part |
Maximum Working Pressure (psi) |
Tube O.D. (mm) |
Stem Type |
Valve Type |
| 20MVBB |
20,000 |
6.35 mm |
Vee |
Rising Stem |
| 20MVBB6 |
20,000 |
9.53 mm |
Vee |
Rising Stem |
|
