Parker Fittings接头
Hose Fittings
High Pressure Plugs
High pressure plugs are designed to be used with Polyflex high pressure fittings.
High pressure plugs are designed to be used with Polyflex high pressure fittings.
Markets:
- Hydraulics
- Industrial
- Oil & Gas
Features:
- Keeps contaminants/dust from getting into the connection opens
- Protects connection ends from damage
- Easy to put on and remove
Technical Specifications
| Overall Length: |
Varies, Varies |
| Shape: |
Straight |
| Application: |
Oilfield, Marine |
| Connection Type: |
Field-Attachable |
| Hose Inside Diameter: |
1/16, 1/8, 1/4, 3/8, 1/2, 9/16, 5/8, 3/4, 1 inch, 1, 3, 6, 10, 13, 14, 16, 19, 25 mm |
| Maximum Operating Pressure: |
4140 bar, 414 MPa, 60,000 psi |
| Hex Size: |
0.5, 0.625, 0.812, 0.937, 1.375, 0.69, 1, 1.25, 1.5, 1.125, 0.375 inch, 12.7, 15.88, 20.62, 23.8, 34.93, 17.53, 25.4, 31.75, 38.1, 28.58, 9.53 mm |
| Tube Outside Diameter: |
1/4, 3/8, 9/16, 3/4, 1 inch |
| Materials of Construction: |
Stainless Steel |
High Pressure Plugs 型号
|
