McDaniel Controls, Inc. Plant Safety Gauges工厂安全仪表
McDaniel工厂安全仪表Plant Safety Gauges
工厂安全仪表-提供超过35年的安全性、耐久性和准确性Plant Safety Gauges -Providing the Ultimate in Safety, Durability and Accuracy for over 35 Years
特征Features:
实心前/全喷后铰链，以减少弹丸的使用风险，设计在300%满量程压力范围内，波登管不破裂，刻度盘上零位无指针停止，可能造成零压力错误指示，终极安全，耐用，维修功能，保修，可填充外壳，防风雨，螺旋波登管Solid front/full blowout back hinged to reduce the risk of becomming a projectile ,Design over range of 300% full scale pressure without rupture of Bourdon tube,No pointer stop at zero position on dial to possibly create a false indication of zero pressure, Ultimate Safety , Durable , Repair Feature , Warranty , Fillable case , Weather Protected , Spiral Bourdon Tube , Last Word
McDaniel Controls, Inc. Plant Safety Gauges工厂安全仪表资料下载
模型
MODEL |
刻度盘大小
DIAL SIZE |
可填充
FILLABLE |
连接
CONNECTION |
案例
CASE |
内部构件
INTERNALS |
特征
FEATURES |
| PSGA |
4 1/2 inch (130mm) |
Kit |
Options (1/4) |
Fiberglass reinforced thermoplastic |
316 Stainless Steel |
SF/BOB. Polyacetate Hinged for Safety |
| PSGC |
4 1/2 inch (130mm) |
Kit |
Options (1/2) |
Fiberglass reinforced thermoplastic |
316 Stainless Steel |
SF/BOB. Polyacetate Hinged for Safety |
Model PSGA
Plant Safety Gauges 4 1/2" Dial Size - Liquid Fillable - 1/4" NPT
| 标准和可选功能Standard and optional features |
| 刻度盘大小Dial size: |
4 1/2 inch (130mm) |
| 可填充：Fillable: |
Kit |
| 连接Connection: |
1/4" NPT or Metric |
| 案例Case: |
Fiberglass reinforced thermoplastic |
| 内部构件Internals: |
316 Stainless Steel |
| Wetted parts: |
316 Stainless steel (C Form 600 PSI & Below). (Spiral 800 PSI & Above). |
| 准确度Accuracy: |
0.5 % full scale to ASME B40.1 standard (Grade 2A) |
| 范围Ranges: |
Vacuum,Rec.,Compound,0-20,000 psi |
| 安装Mount: |
Standard Bottom Connection |
| 比例尺Scale: |
B=psi/Bar(dual scale), K=psi/kPa(dual scale),psi/kg/cm2(dual scale) |
| 选项Options: |
Laminated Safety Glass lens, Stainless Steel Tags |
| 填充选项Fill Option: |
Fill Kit |
Model PSGC
Plant Safety Gauges 4 1/2" Dial Size - Liquid Fillable - 1/2" NPT
| 标准和可选功能Standard and optional features |
| 刻度盘大小Dial size: |
4 1/2 inch (130mm) |
| 可填充：Fillable: |
Kit |
| 连接Connection: |
1/2" NPT or Metric |
| 案例Case: |
Fiberglass reinforced thermoplastic |
| 内部构件Internals: |
316 Stainless Steel |
| Wetted parts: |
316 Stainless steel (C Form 600 PSI & Below). (Spiral 800 PSI & Above). |
| 准确度Accuracy: |
0.5 % full scale to ASME B40.1 standard (Grade 2A) |
| 范围Ranges: |
Vacuum,Rec.,Compound,0-20,000 psi |
| 安装Mount: |
Standard Bottom Connection |
| 比例尺Scale: |
B=psi/Bar(dual scale), K=psi/kPa(dual scale),psi/kg/cm2(dual scale) |
| 选项Options: |
Laminated Safety Glass lens, Stainless Steel Tags |
| 填充选项Fill Option: |
Fill Kit |
|
